Code: Select all
root@bbebcf8214f6:/home# ./build.sh uboot
**************************************
Check [OK]: dtc --version
**************************************
Check [OK]: makeinfo --version
**************************************
Check [OK]: gperf --version
**************************************
Check [OK]: dpkg --list |grep g++-.*-multilib
**************************************
Check [OK]: dpkg --list |grep gcc-.*-multilib
**************************************
Check [OK]: make -v
GLOBAL_PARTITIONS: 0x40000@0x0(env),0x40000@0x40000(idblock),0x80000@0x80000(uboot),0x400000@0x100000(boot),0x1E00000@0x500000(oem),0xA00000@0x2300000(userdata),0x5000000@0x2D00000(rootfs)
[build.sh:info] Partition Filesystem Type Configure: rootfs@IGNORE@ubifs,oem@/oem@ubifs,userdata@/userdata@ubifs
============Start building uboot============
TARGET_UBOOT_CONFIG=rv1106_defconfig rk-sfc.config
=========================================
make: Entering directory '/home/sysdrv'
==sysdrv== build uboot
make[1]: Entering directory '/home/sysdrv/source/uboot/u-boot'
#
# configuration written to .config
#
Using .config as base
Merging ./arch/../configs/rk-sfc.config
Value of CONFIG_ROCKCHIP_SFC_IOMUX is redefined by fragment ./arch/../configs/rk-sfc.config:
Previous value: # CONFIG_ROCKCHIP_SFC_IOMUX is not set
New value: CONFIG_ROCKCHIP_SFC_IOMUX=y
#
# merged configuration written to .config (needs make)
#
scripts/kconfig/conf --oldconfig Kconfig
#
# configuration written to .config
#
make[1]: Leaving directory '/home/sysdrv/source/uboot/u-boot'
pushd /home/sysdrv/source/uboot/u-boot;/home/sysdrv/source/uboot/u-boot/make.sh --spl-new CROSS_COMPILE=arm-rockchip830-linux-uclibcgnueabihf-;popd
/home/sysdrv/source/uboot/u-boot /home/sysdrv
make[1]: Entering directory '/home/sysdrv/source/uboot/u-boot'
scripts/kconfig/conf --silentoldconfig Kconfig
CHK include/config.h
CFG u-boot.cfg
GEN include/autoconf.mk.dep
CFG spl/u-boot.cfg
CFG tpl/u-boot.cfg
GEN include/autoconf.mk
GEN tpl/include/autoconf.mk
GEN spl/include/autoconf.mk
CHK include/config/uboot.release
CHK include/generated/timestamp_autogenerated.h
UPD include/generated/timestamp_autogenerated.h
CHK include/generated/version_autogenerated.h
CHK include/generated/generic-asm-offsets.h
CHK include/generated/asm-offsets.h
HOSTCC tools/mkenvimage.o
HOSTCC tools/fit_image.o
HOSTCC tools/image-host.o
HOSTCC tools/dumpimage.o
HOSTCC tools/mkimage.o
HOSTCC tools/rockchip/boot_merger.o
HOSTCC tools/rockchip/loaderimage.o
HOSTLD tools/mkenvimage
HOSTLD tools/loaderimage
CHK include/config.h
CFG u-boot.cfg
HOSTLD tools/dumpimage
HOSTLD tools/mkimage
tools/rockchip/boot_merger.c: In function 'mergeBoot':
tools/rockchip/boot_merger.c:700:43: warning: '%s' directive output may be truncated writing up to 813 bytes into a region of size 5 [-Wformat-truncation=]
700 | snprintf(buffer, sizeof(buffer), "%s", chip);
| ^~
......
742 | chipType = convertChipType(chip + 2);
| ~~~~~~~~~~~~~~~~~~~~~~~~~
In file included from /usr/include/stdio.h:894,
from ././include/compiler.h:25,
from <command-line>:
/usr/include/x86_64-linux-gnu/bits/stdio2.h:71:10: note: '__builtin_snprintf' output between 1 and 814 bytes into a destination of size 5
71 | return __builtin___snprintf_chk (__s, __n, __USE_FORTIFY_LEVEL - 1,
| ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
72 | __glibc_objsize (__s), __fmt,
| ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
73 | __va_arg_pack ());
| ~~~~~~~~~~~~~~~~~
tools/rockchip/boot_merger.c: In function 'main':
tools/rockchip/boot_merger.c:895:18: warning: array subscript 20 is outside array bounds of 'char[20]' [-Warray-bounds]
895 | str[len] = 0;
| ~~~~~~~~~^~~
tools/rockchip/boot_merger.c:933:14: note: while referencing 'name'
933 | char name[MAX_NAME_LEN];
| ^~~~
HOSTLD tools/boot_merger
CC cmd/version.o
CC common/main.o
LD cmd/built-in.o
LD common/built-in.o
CC lib/display_options.o
LD lib/built-in.o
LD u-boot
OBJCOPY u-boot.srec
OBJCOPY u-boot-nodtb.bin
SYM u-boot.sym
make[3]: 'arch/arm/dts/rv1106-evb.dtb' is up to date.
MKIMAGE u-boot.img
COPY u-boot.dtb
MKIMAGE u-boot-dtb.img
CAT u-boot-dtb.bin
COPY u-boot.bin
ALIGN u-boot.bin
CC spl/common/spl/spl.o
CC tpl/arch/arm/mach-rockchip/tpl.o
COPY spl/u-boot-spl.dtb
CC spl/lib/display_options.o
LD tpl/arch/arm/mach-rockchip/built-in.o
LD spl/common/spl/built-in.o
LD tpl/u-boot-tpl
LD spl/lib/built-in.o
OBJCOPY tpl/u-boot-tpl-nodtb.bin
COPY tpl/u-boot-tpl.bin
LD spl/u-boot-spl
OBJCOPY spl/u-boot-spl-nodtb.bin
CAT spl/u-boot-spl-dtb.bin
COPY spl/u-boot-spl.bin
CFGCHK u-boot.cfg
make[1]: Leaving directory '/home/sysdrv/source/uboot/u-boot'
WARN: No tee bin
pack u-boot.itb okay! Input: /home/sysdrv/source/uboot/rkbin/RKTRUST/RV1106TOS.ini
FIT description: FIT Image with ATF/OP-TEE/U-Boot/MCU
Created: Fri Jun 7 16:55:57 2024
Image 0 (uboot)
Description: U-Boot
Created: Fri Jun 7 16:55:57 2024
Type: Standalone Program
Compression: lzma compressed
Data Size: 173165 Bytes = 169.11 KiB = 0.17 MiB
Architecture: ARM
Load Address: 0x00200000
Entry Point: unavailable
Hash algo: sha256
Hash value: 5f5e48c368f3ee93b9cc3f4b157bdba5e576dbf99d5a9cbf0f4ca823e6480be1
Image 1 (fdt)
Description: U-Boot dtb
Created: Fri Jun 7 16:55:57 2024
Type: Flat Device Tree
Compression: uncompressed
Data Size: 7784 Bytes = 7.60 KiB = 0.01 MiB
Architecture: ARM
Hash algo: sha256
Hash value: 51bba657c35430930647b6cfb31010e5cbd496848b5529f224131ab972111f91
Default Configuration: 'conf'
Configuration 0 (conf)
Description: rv1106-evb
Kernel: unavailable
FDT: fdt
Loadables: uboot
********boot_merger ver 1.2********
Info:Pack loader ok.
creating new idblock from loader...
idblock binary saving at rv1106_idblock_v1.10.101.img
pack loader(SPL) okay! Input: /home/sysdrv/source/uboot/rkbin/RKBOOT/RV1106MINIALL.ini
/home/sysdrv/source/uboot/u-boot
pack loader with new: spl/u-boot-spl.bin
Image(no-signed, version=0): uboot.img (FIT with uboot, trust...) is ready
Image(no-signed): rv1106_idblock_v1.10.101.img (with spl, ddr...) is ready
pack uboot.img okay! Input: /home/sysdrv/source/uboot/rkbin/RKTRUST/RV1106TOS.ini
Platform RV1106 is build OK, with exist .config
arm-rockchip830-linux-uclibcgnueabihf-
Fri Jun 7 16:55:57 HKT 2024
/home/sysdrv
'/home/sysdrv/source/uboot/u-boot/uboot.img' -> '/home/sysdrv/out/image_uclibc_rv1106/uboot.img'
'/home/sysdrv/source/uboot/u-boot/rv1106_idblock_v1.10.101.img' -> '/home/sysdrv/out/image_uclibc_rv1106/idblock.img'
'/home/sysdrv/source/uboot/u-boot/rv1106_download_v1.10.106.bin' -> '/home/sysdrv/out/image_uclibc_rv1106/download.bin'
[INSTALL] /home/sysdrv/out/image_uclibc_rv1106/idblock.img /home/sysdrv/out/image_uclibc_rv1106/uboot.img /home/sysdrv/out/image_uclibc_rv1106/download.bin
TO /home/output/image
make: Leaving directory '/home/sysdrv'
[build.sh:info] Running build_uboot succeeded.
